MF72-NTC**D-13 Series

Introduce

Targeted at larger power systems, the D-13 series supports higher inrush currents and is commonly used in power tools, EV charging stations, and UPS systems with stringent surge suppression requirements.

Inquiry

A^-A⁺

Parameter Inquiry

Part Number	Resistance at 25℃	Max. Permissible Working Curren	Resistance under Load	Dissipation Factor	Thermal Time Constan	Maximum permissible capacitance @240Vac
Part Number	R25 (Ω) ±20%	Imax (A)	(mΩ)	δ(mW/℃)	τ(Sec.)	C（uF）
MF72-NTC1.3D-13	1.3	7	62	13	60	330
MF72-NTC2.5D-13	2.5	6	88	13	60	330
MF72-NTC3D-13	3	6	92	14	60	330
MF72-NTC4D-13	4	5	124	16	65	330
MF72-NTC5D-13	5	5	125	15	68	330
MF72-NTC8D-13	8	4	194	15	60	330
MF72-NTC10D-13	10	4	206	15	65	330
MF72-NTC16D-11	16	2	470	14	50	220
MF72-NTC20D-11	20	2	613	14	52	220
